塑料绝缘控制电缆 |
|
型号 |
产品名称 |
敷设场合及要求 |
导体长期允许 |
额定电压 V |
标称截面mm2 |
|
|---|---|---|---|---|---|---|
|
KVV |
铜芯聚氯乙烯/交联聚乙烯绝缘聚氯乙烯护套控制电缆 |
敷设在室内、电缆沟 、管道等固定场合 |
70 90 |
450/750 |
0.5 ~ 10 |
|
|
KVVP |
铜芯聚氯乙烯/交联聚乙烯绝缘聚氯乙烯护套编织屏蔽控制电缆 |
敷设在室内、电缆沟 、管道等要求防干扰的固定场合 |
||||
|
KVVP2 |
铜芯聚氯乙烯/交联聚乙烯绝缘聚氯乙烯护套铜带屏蔽控制电缆 |
|||||
|
KVV22 |
铜芯聚氯乙烯/交联聚乙烯绝缘聚氯乙烯护套钢带铠装控制电缆 |
敷设在室内、电缆沟、管道、直埋等能承受较大机械外力等固定场合 |
||||
|
KVV32 |
铜芯聚氯乙烯/交联聚乙烯绝缘聚氯乙烯护套细钢丝铠装控制电缆 |
敷设在室内、电缆沟、管道、竖井等能承受较大机械拉力等固定场合 |
||||
|
KVVR |
铜芯聚氯乙烯/交联聚乙烯绝缘聚氯乙烯护套控制软电缆 |
敷设在室内、移动要求柔软等场合 |
||||
|
KVVRP |
铜芯聚氯乙烯/交联聚乙烯绝缘聚氯乙烯护套编织屏蔽控制软电缆 |
敷设在室内、移动要求柔软、防干扰等场合 |
||||
|
电缆结构/尺寸表 |
||||||
|
电缆结构/尺寸表 |
|
芯数x截面 |
电缆外径上限 |
||||||||
|---|---|---|---|---|---|---|---|---|---|
|
KVV |
KVVP |
KVVP2 |
KVV22 |
KVV32 |
KVVR |
KVVRP |
|||
|
2X0.75 |
8.0 |
9.3 |
|
|
|
|
|
||
|
2X1.0 |
8.3 |
9.6 |
|
|
|
|
|
||
|
2X1.5 |
9.3 |
10.6 |
|
|
|
|
|
||
|
2X2.5 |
10.8 |
11.9 |
|
|
|
|
|
||
|
2X4 |
11.8 |
13.9 |
|
|
|
|
|
||
|
2X6 |
13.0 |
15.0 |
|
|
|
|
|
||
|
2X10 |
16.3 |
17.8 |
|
|
|
|
|
||
|
3X0.75 |
8.3 |
9.6 |
|
|
|
|
|
||
|
3X1.0 |
8.8 |
10.0 |
|
|
|
|
|
||
|
3X1.5 |
9.9 |
11.1 |
|
|
|
|
|
||
|
3X2.5 |
11.3 |
12.6 |
|
|
|
|
|
||
|
3X4 |
12.5 |
14.5 |
|
|
|
|
|
||
|
3X6 |
13.3 |
15.8 |
|
|
|
|
|
||
|
3X10 |
17.5 |
18.7 |
|
|
|
|
|
||
|
4X0.5 |
|
|
|
|
|
8.7 |
9.9 |
||
|
4X0.75 |
9.1 |
10.3 |
9.2 |
|
|
9.3 |
10.5 |
||
|
4X1.0 |
9.5 |
10.7 |
9.6 |
|
|
9.6 |
10.8 |
||
|
4X1.5 |
10.7 |
11.9 |
10.7 |
|
|
10.9 |
12.1 |
||
|
4X2.5 |
12.4 |
14.4 |
12.9 |
|
|
12.5 |
14.6 |
||
|
4X4 |
14.3 |
15.7 |
14.0 |
16.5 |
19.6 |
|
|
||
|
4X6 |
15.6 |
17.0 |
15.2 |
17.8 |
20.2 |
|
|
||
|
4X10 |
18.9 |
20.8 |
19.8 |
22.4 |
25.8 |
|
|
||
|
5X0.5 |
|
|
|
|
|
9.3 |
10.5 |
||
|
5X0.75 |
9.8 |
11.0 |
9.9 |
|
|
|
|
||
|
5X1.0 |
10.2 |
11.4 |
10.3 |
|
|
|
|
||
|
5X1.5 |
11.6 |
12.8 |
12.2 |
|
|
|
|
||
|
5X2.5 |
14.1 |
15.5 |
13.9 |
|
|
|
|
||
|
5X4 |
15.5 |
16.9 |
15.1 |
17.6 |
20.8 |
|
|
||
|
5X6 |
17.0 |
18.4 |
16.5 |
19.5 |
22.2 |
|
|
||
|
5X10 |
21.8 |
22.6 |
22.2 |
24.1 |
27.6 |
|
|
||
|
7X0.5 |
|
|
|
|
|
10.0 |
11.2 |
||
|
7X0.75 |
10.5 |
11.7 |
10.5 |
13.7 |
|
10.8 |
12.0 |
||
|
7X1.0 |
11.0 |
12.2 |
11.0 |
14.2 |
|
11.2 |
12.4 |
||
|
7X1.5 |
12.5 |
14.4 |
13.1 |
15.6 |
17.6 |
12.8 |
14.7 |
||
|
7X2.5 |
15.3 |
16.7 |
14.9 |
17.5 |
20.6 |
15.4 |
16.8 |
||
|
7X4 |
16.8 |
18.2 |
16.3 |
18.9 |
22.0 |
|
|
||
|
7X6 |
18.5 |
19.9 |
17.9 |
20.9 |
24.3 |
|
|
||
|
7X10 |
23.6 |
24.2 |
24.1 |
26.0 |
29.5 |
|
|
||
|
|
|||||||||
|
芯数x截面 |
电缆外径上限 |
||||||
|---|---|---|---|---|---|---|---|
|
KVV |
KVVP |
KVVP2 |
KVV22 |
KVV32 |
KVVR |
KVVRP |
|
|
8X0.5 |
|
|
|
|
|
10.5 |
11.7 |
|
8X0.75 |
11.0 |
12.2 |
11.7 |
14.3 |
|
11.3 |
12.5 |
|
8X1.0 |
11.6 |
13.5 |
12.2 |
14.8 |
|
11.8 |
13.6 |
|
8X1.5 |
13.9 |
15.3 |
13.7 |
16.3 |
19.4 |
14.2 |
15.6 |
|
8X2.5 |
16.1 |
17.5 |
15.7 |
18.3 |
21.4 |
16.3 |
17.7 |
|
8X4 |
17.8 |
19.6 |
17.7 |
20.2 |
23.7 |
|
|
|
8X6 |
20.1 |
21.5 |
19.3 |
21.9 |
25.4 |
|
|
|
8X10 |
25.1 |
26.1 |
25.5 |
27.5 |
30.9 |
|
|
|
10X0.5 |
|
|
|
|
|
12.2 |
14.1 |
|
10X0.75 |
12.9 |
15.0 |
13.5 |
16.0 |
|
13.3 |
15.3 |
|
10X1.0 |
14.3 |
15.7 |
14.1 |
16.7 |
|
14.5 |
15.9 |
|
10X1.5 |
16.3 |
17.7 |
16.0 |
18.5 |
21.6 |
16.7 |
18.1 |
|
10X2.5 |
19.1 |
20.5 |
18.9 |
21.5 |
24.9 |
19.3 |
20.7 |
|
10X4 |
22.1 |
22.9 |
21.4 |
23.3 |
26.8 |
|
|
|
10X6 |
24.4 |
25.4 |
23.4 |
25.4 |
28.8 |
|
|
|
10X10 |
29.9 |
30.9 |
30.3 |
33.0 |
37.9 |
|
|
|
12X0.5 |
|
|
|
|
|
12.6 |
14.4 |
|
12X0.75 |
13.9 |
15.3 |
13.8 |
16.4 |
|
14.3 |
15.7 |
|
12X1.0 |
14.7 |
16.1 |
14.5 |
17.0 |
|
14.9 |
16.3 |
|
12X1.5 |
16.7 |
18.1 |
16.4 |
19.0 |
22.1 |
17.2 |
18.6 |
|
12X2.5 |
19.6 |
21.5 |
19.5 |
22.0 |
25.5 |
20.5 |
21.7 |
|
12X4 |
22.8 |
23.6 |
22.0 |
24.0 |
27.4 |
|
|
|
12X6 |
25.2 |
26.2 |
24.1 |
26.1 |
29.5 |
|
|
|
14X0.5 |
|
|
|
|
|
13.2 |
15.2 |
|
14X0.75 |
14.6 |
16.0 |
14.4 |
17.0 |
|
15.0 |
16.4 |
|
14X1.0 |
15.4 |
16.8 |
15.1 |
17.7 |
|
15.6 |
17.0 |
|
14X1.5 |
17.5 |
18.9 |
17.2 |
20.2 |
23.6 |
18.0 |
19.7 |
|
14X2.5 |
21.2 |
22.5 |
20.4 |
22.9 |
26.0 |
21.5 |
22.7 |
|
14X4 |
23.9 |
24.7 |
23.0 |
25.0 |
28.5 |
|
|
|
14X6 |
26.4 |
27.4 |
25.3 |
27.2 |
30.7 |
|
|
|
16X0.5 |
|
|
|
|
|
14.5 |
15.9 |
|
16X0.75 |
15.3 |
16.7 |
15.1 |
17.6 |
|
15.7 |
17.1 |
|
16X1.0 |
16.1 |
17.5 |
15.8 |
18.4 |
|
16.4 |
17.8 |
|
16X1.5 |
18.4 |
19.8 |
18.0 |
21.0 |
24.5 |
18.9 |
20.3 |
|
16X2.5 |
22.8 |
23.6 |
22.0 |
23.9 |
27.4 |
23.0 |
23.8 |
|
19X0.5 |
|
|
|
|
|
15.2 |
16.6 |
|
19X0.75 |
16.0 |
17.4 |
15.8 |
18.3 |
21.4 |
16.5 |
17.9 |
|
19X1.0 |
16.9 |
18.3 |
16.6 |
19.5 |
22.2 |
17.2 |
18.6 |
|
19X1.5 |
19.4 |
21.2 |
19.3 |
21.9 |
25.4 |
20.5 |
21.7 |
|
19X2.5 |
23.9 |
24.7 |
23.0 |
25.0 |
28.5 |
24.2 |
25.0 |
